Model M

180º Upward cleaning

Optimized Spray Pattern

Other spray pattern

High reliability

No internal parts or seals; high reliability, low maintance

Constant Rotation

Constant rotation due to reactive force of two flat nozzles

Precise targeting

Adjustable positioning for tailored coverage

Cleaning agents

High impact cleaning with foam or water

Industry

Food & bevarage, CIP-installations, tank cleaning

Efficiënt cleaning

Efficiënt cleaning with reduced water and chemical usage

Common use

Ideal for cleaning tank domes or ceilings

Robust

Works effectively under both high and low pressure

Model W Compatible

Combines with Model W for multi-directional cleaning

Wide cover area

Covers 180º area below the spray head

GyraFlex Model M

The GyraFlex Model M is designed for 180º upward cleaning, making it ideal for tank domes and ceilings. With no internal parts or seals, it offers high reliability and low maintenance even in demanding applications.

Two flat spray nozzles provide constant rotation through reactive force, ensuring consistent cleaning performance. The nozzles allow adjustable positioning, giving tailored coverage to meet specific cleaning requirements. Engineered for efficiency, the Model M reduces water and chemical consumption while maintaining effective cleaning under both high and low pressure conditions. For extended coverage or multi-directional cleaning, the Model M can be combined with the GyraFlex Model W.

For detailed specifications and configuration options, please contact our technical team.

Technical details

Pressure: 2-20 bar
Temperature: Min 2ºC - Max: 200ºC
Materials: PTFE Body with stainless steel 316 components
Angle guide: <5 bar: 95º | >5 bar: 80º
Cleaning: 180º upward
Clearance (mm): 105- 160
Spray Coverage (m): 6 wide, 1.5 high
Spray Pattern: Optimized for 180º upward cleaning
Compatibility: Model W | 1/4" flat spray nozzles
